REFERENCE 4c
REFERENCE 4c
Regular price
$12,995.00 AUD
Regular price
$12,995.00 AUD
Sale price
$12,995.00 AUD
Unit price
/
per
DESIGN | Three-way bass reflex |
---|---|
DRIVE UNITS | Uni-Q driver array: HF: 25mm (1in.) vented aluminium dome MF: 125mm (5in.) aluminium Bass units: LF: 4 x165mm (6.5in.) aluminium |
FREQUENCY RANGE | Typical in room bass response: 33Hz (-6dB) Free Field - Short port: 43Hz - 45kHz (-6dB) Free Field - Long port: 40Hz - 45kHz (-6dB) |
FREQUENCY RESPONSE | 48Hz - 35kHz (±3dB) |
CROSSOVER FREQUENCIES | 350Hz, 2.8kHz |
MAXIMUM OUTPUT | 116dB (peak sound pressure level at 1m with pink noise) |
AMPLIFIER CLASS | 50-400 W |
SENSITIVITY | 90dB (2.83V/1m) |
HARMONIC DISTORTION | 2nd & 3rd harmonics (90dB, 1m) <0.5% 40Hz – 100kHz <0.2% 200Hz – 10kHz |
IMPEDANCE | 8 Ohms (min.3.2 Ohms) |
DIMENSIONS | H x W x D with grille, terminal & plinth : 205 x 1090 x 470 mm (8.1 x 42.9 x 18.5 in.) |
WEIGHT | 45.2kg (99.6lbs) |
UNIT MEASUREMENT | Piece |
DOCUMENT DOWNLOAD |
THE REFERENCE Brochure THE REFERENCE Manual THE REFERENCE 8b Manual THE REFERENCE White Paper THE REFERENCE Information Sheet |
