R3
R3
Regular price
$3,595.00 AUD
Regular price
$3,695.00 AUD
Sale price
$3,595.00 AUD
Unit price
/
per
MODEL | R3 |
---|---|
DESIGN | Three-way bass reflex |
DRIVE UNITS | Uni-Q Driver Array: HF: 25mm (1in.) vented aluminium dome MF: 125mm (5in.) aluminium cone Bass Driver: LF: 165mm (6.5in.) hybrid aluminium |
CROSSOVER FREQUENCIES | 400Hz, 2.9kHz |
FREQUENCY RANGE | 38Hz-50kHz (-6dB) |
TYPICAL IN-ROOM BASS RESPONSE | 30Hz (-6dB) |
FREQUENCY RESPONSE | 58Hz-28kHz (±3dB) |
HARMONIC DISTORTION | <0.3% 130Hz-20kHz (90dB, 1m) |
MAXIMUM OUTPUT | 110dB |
AMPLIFIER POWER | 15-180W |
NOMINAL IMPEDANCE | 8Ohms (min.3.2Ohms) |
WEIGHT | 13.5 kg (29.8 lbs.) |
DIMENSION (H X W X D) | 422.2 x 199.6 x 335.5 mm (16.6 x 7.9 x 13.2 in.) with terminal* |
DIMENSION (H X W X D) | 422 x 199.6 x 312 Cabinet only |
FINISHES | Black Gloss / White Gloss / Walnut |
DOCUMENT DOWNLOAD |
R Series White Paper R Series Brochure R Series Information Sheet R Series User Manual Maintenance Guide for R Series Microfibre Grille |
REMARKS | * Measurement per unit |
