• Total Pieces

  2

ACCESSORIES

• Included Accessories

  • (1) Grille
  • (1) Removable Base

WARRANTY

• Cabinet Warranty

  5 years

• Drivers Warranty

  5 years

• Original Purchaser Only

  Yes

SHIPPING CARTONS

• Carton 1

  11.25" (28.58 cm) h x 11" (27.94 cm) w x 11" (27.94 cm) d - 10.5 lbs (4.76 kg)

• Qty Included

  Pair

• Availability

   US

• Orientation

  • Vertical
  • Horizontal

• Height

  10" (25.4 cm)

• Width

  7" (17.78 cm)

• Depth

  4" (10.16 cm)

• Weight

  4 lbs (1.81 kg)

• Front Array Driver Complement

  • (1)  4.5" (11.43 cm) d (Round) - Mid/Woofer
  • (1)  1" (2.54 cm) d (Round) - Tweeter

AUDIO QUALITY

• Total Frequency Response

  80 Hz → 25 Hz

• Nominal Impedance

  8|||| ohms

• Sensitivity (1 watt @ 1 meter)

  89 dB

• Lower and Upper -3dB Limits

  100 Hz → 22 Hz

ANGLED WALL MOUNT MOUNT

• Mounting Type

  Keyhole Hanger

• Available Orientations

  • Vertical
  • Horizontal

• Mounting Location

  • Back of Speaker
  • Bottom of Speaker

  Near: Bottom, Center

SWIVEL WALL/CEILING MOUNT MOUNT

• Mounting Type

  1/4" 20 Threaded Insert

• Available Orientations

  • Horizontal
  • Vertical

• Mounting Location

  • Back of Speaker
  • Bottom of Speaker

  Near: Bottom, Center

ON-SHELF MOUNT

• Mounting Type

  Keyhole Hanger

• Available Orientations

  Horizontal

• Mounting Location

  Back of Speaker - Near: Center

CORNER MOUNT MOUNT

• Mounting Type

  Keyhole Hanger

• Available Orientations

  • Horizontal
  • Vertical

• Mounting Location

  • Back of Speaker
  • Bottom of Speaker

  Near: Bottom, Center

EXTERNAL AMPLIFIER

• Recommended Amplifier Power Per Channel

  20 watts → 100 watts

INPUTS

• Audio Inputs

• Speaker Inputs

  (1) 5-way Binding Posts - Gold-Plated
