LUXMAN

MQ-88uC

MQ-88uC

$0.00 AUD
$0.00 AUD
Sale Sold out

Specifications:

Rated output 25W + 25W (4Ω, 8Ω, 16Ω)
Input sensitivity 890mV/25W
input impedance 32kΩ
Frequency response 20Hz to 20kHz (+0, -0.5dB)
10Hz to 100kHz (+0, -3.0dB)
Total harmonic distortion 0.1% (1kHz/1W)
0.5% (20Hz to 20kHz/1W)
S/N ratio (IHF-A) 105dB
Circuit Driver: Mullard, Output tubes: Triode connection
Vacuum tubes ECC83S×2, ECC82×2, KT88×4
Power supply 230V~(50Hz)/115V~(60Hz)
Power consumption 170W, 140W (under no signal)
External dimensions 440(W) x 184(H) x 230(D) mm
17mm front panel knob of and 28mm rear panel
terminals are included in the depth measurement
Net weight 16.1kg (main unit)
Accessories Power cable
Speaker terminal Supported Y-lug terminal dimension Width of part a: 14.5mm or less
Width of part b: 7.5mm or more
*Connection may be difficult
depending on the shape of the Y-lug terminal.
