Specfications:
| Rated output | 8W + 8W (4Ω, 8Ω,16Ω) |
|---|---|
| Input sensitivity | 490mV (8Ω) |
| Input impedance | 240kΩ |
| Frequency response | 20Hz to 20kHz (+0.3,-1.5dB) 10Hz to 30kHz (+0.3, -3.0dB) |
| Total harmonic distortion | 1% (1kHz, 8Ω, 1W) |
| S/N ratio (IHF-A) | 105dB |
| Circuiting system | Driver: Parallel connection two stage amplification Output: Single configuration, cathod-bias circuit Whole: Non-feedback amplification |
| Vacuum tubes | 5AR4(SOVTEK) x 2 6SN7GTB(TUNG-SOL) x 4 TA-300B(Takatsuki) x 2 |
|---|---|
| Power voltage | 230V~(50Hz) / 115V~(60Hz) |
| Power consumption | 190W 190W (at no input) |
| External dimensions | 460(W) x 237(H) x 340(D) mm rear side terminal of 36mm included in depth |
| Net weight | 29.0kg (main unit) |
| Accessories | Power cable |
| Speaker terminal Supported Y-lug terminal dimension | Width of part a: 16mm or less Width of part b: 7mm or more * Connection may not be performed depending on the shape of the Y-lug terminal. |
