Martin Logan
Motion 50XT
Motion 50XT
Couldn't load pickup availability
|
Frequency Response |
50–25,000 Hz ±3dB |
|
Recommended Amplifier Power |
20—300 watts per channel |
|
Horizontal Dispersion |
80° |
|
Vertical Dispersion |
30° |
|
Sensitivity |
94 dB/2.83 volts/meter |
|
Impedance |
4 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers. |
|
Crossover Frequency |
900 & 2,200 Hz |
|
High Frequency Transducer |
1.25" × 2.4" (3.2cm × 6.1cm) Folded Motion XT Transducer with 4.5" x 2.75" (11.4cm × 7cm) diaphragm |
|
Low Frequency Transducer |
Two 6.5" (16.5cm) aluminum cone with cast poly- mer basket. Non-resonant asymmetrical chamber format. Rigid structured dust cap to reduce cone break-up modes. |
|
Components |
Custom air core coil and low DCR steel laminate inductors. Polyester film capacitors in series and low DF electrolytic capacitors in parallel. Tweeter thermal/current protection. |
|
Inputs |
Custom 5-way bi-wire tool-less binding posts |
|
Weight |
30.5 lbs. (13.8 kg) |
|
Dimensions |
7.6" x 22.8" x 12.8 " |
