Frequency Response
|
40–25,000 Hz ±3dB
|
|
Recommended Amplifier Power
|
20—300 watts per channel
|
|
Horizontal Dispersion
|
80°
|
|
Vertical Dispersion
|
80°
|
|
Sensitivity
|
92 dB/2.83 volts/meter
|
|
Impedance
|
4 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers.
|
|
Crossover Frequency
|
500 & 2,600 Hz
|
|
High Frequency Transducer
|
1" × 1.4" (2.6cm × 3.6cm) Folded Motion Transducer with 5.25" × 1.75" (13.3cm × 4.4cm) diaphragm
|
|
Mid Frequency Transducer
|
5.5" (14cm) aluminum cone in a non-resonant asymmetrical chamber format. Cast polymer basket. Rigid structured dustcap reduces cone break-up.
|
|
Low Frequency Transducer
|
Two 6.5" (16.5cm) aluminum cone woofers in a non-resonant asymmetrical chamber format. Cast polymer basket. Rigid structured dust caps reduce cone break-up.
|
|
Components
|
Precision Vojtko™ with custom air core coil and low DCR steel laminate inductors. Polyester film capacitors in series and low DF electrolytic capacitors in parallel
|
|
Inputs
|
Custom 5-way bi-wire tool-less binding posts
|
|
Weight
|
49 lbs. (22.2 kg)
|
|
Dimensions
|
42.5" x 7.6" x 12.8 " (107.9cm x 19.2cm x 32.6cm)
|
