Regular price $15,499.00 AUD
Regular price $15,999.00 AUD Sale price $15,499.00 AUD
Sale Sold out


Rated output Speaker terminal Supported Y-lug terminal dimension
Instantaneous max. output 1,200W + 1,200W (1Ω)/at stereo 2,400W (2Ω)/at monaural
Input sensitivity 1.24V/150W (8Ω) GAIN 29.0dB
Input impedance Unbalanced 51 kΩ Balanced 34 kΩ
Frequency response 20Hz to 20kHz (+0, –0.1dB) 1Hz to 130kHz (+0, –3.0 dB)
Total harmonic distortion rate 0.008% or less (1kHz/8Ω) 0.1% or less (20Hz to 20kHz/8Ω)
S/N ratio (IHF-A) 117dB
Amplification circuit ODNF 4.0
Output configuration Bipolar 4-parallel push-pull x 2
Power transformer EI type 1,250VA
Damping factor 710
Power consumption 540W 280W (under no signal) 1.0W (at standby)
External dimensions 440(W) x 224(H) x 485(D) mm front side knob of 2mm and rear side terminal of 38 mm included in depth
Net weight 48.0kg
Accessories Dedicated remote cable Power cable
Speaker terminal Supported Y-lug terminal dimension Width of part a: 14mm or less Width of part b: 7mm or more
* Connection may not be performed depending
on the shape of the Y-lug terminal.
