LUXMAN

M-700u

Name: M-700u
Brand: LUXMAN
Availability: OutOfStock

$0.00 AUD

~~$0.00 AUD~~ $0.00 AUD

Sale Sold out

Product variants

Quantity

Specs:

Rated output	120W + 120W (8Ω)/at stereo 210W + 210W (4Ω)/at stereo 420W (8Ω)/at monaural
Instantaneous max. output	840W + 840W (1Ω)/at stereo 1,680W (2Ω)/at monaural
Input sensitivity	1.1V/120W (8Ω) GAIN 29.0dB
Input impedance	Unbalanced 51kΩ Balanced 34kΩ
Frequency response	20Hz to 20kHz (+0, –0.1dB) 1Hz to 130kHz (+0, –3.0 dB)
Total harmonic distortion rate	0.009% or less (1kHz/8Ω) 0.1% or less (20Hz to 20kHz/8Ω)
S/N ratio (IHF-A)	115dB
Amplification circuit	ODNF 4.0

Output configuration	Bipolar 4-parallel push-pull
Power transformer	EI type 550VA
Damping factor	350
Power consumption	370W 110W (under no signal) 0.4W (at standby)
External dimensions	440(W) x 190(H) x 427(D) mm front side knob of 2mm and rear side terminal of 38 mm included in depth
Net weight	27.5kg
Accessories	Dedicated remote cable Power cable
Speaker terminal Supported Y-lug terminal dimension	Width of part a: 14mm or less Width of part b: 7mm or more * Connection may not be performed depending on the shape of the Y-lug terminal.
