LUXMAN

M-200

M-200

$2,799.00 AUD
$2,799.00 AUD $2,799.00 AUD
Sale Sold out

Spec

Rated Output 25W + 25W (8Ω) / Stereo, 35W + 35W (4Ω) / Stereo, 70W (8Ω) / BTL Monaural
Gain Stereo 23dB, BTL Monaural 29dB
Sensitivity 1.0V/25W (8Ω)
Impedance LINE 16kΩ, BAL.LINE 33kΩ
Frequency Response 20Hz〜20kHz (+0, -0.2dB), 10Hz〜100kHz (+0, -3.0dB)
Total Harmonic Distortion 0.005% (1kHz/8Ω/25W), 0.06% (20Hz~20kHz/8Ω/12.5W)
S/N Ratio Line 107dB or over, Balance Line 102dB or over
Display Mode Stereo Power Display, BTL Monaural Power Display, Dimmer Adjustment (3 levels), Hold Time Setting (1, 3, 5 seconds), Speaker Impedance Setting (8, 6, 4Ω)
Output configuration bipolar push-pull
Power Transformer EI type 160VA
Damping Factor 100
Power Consumptions 85W, 32W (No input signal)
Dimensions (W x H x D) 364 x 81 x 297 (mm)
Weight 7.0kg
