LUXMAN

L-507UXII

L-507UXII

Regular price $7,499.00 AUD
Regular price $7,999.00 AUD Sale price $7,499.00 AUD
Sale Sold out

Specifications:

Rated output: 110W + 110W (8Ω), 210W + 210W (4Ω)
Input sensitivity/input impedance:
PHONO (MM): 2.5mV/47kΩ
PHONO (MC): 0.3mV/100Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/55kΩ
MAIN-IN: 1.05V/47kΩ
Output voltage: REC OUT: 180mV, PRE-OUT: 1V
Frequency response:
PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB)
Total harmonic distortion:
0.007% or less (8Ω, 1kHz)
0.08% or less (8Ω, 20Hz to 20kHz)
S/N ratio (IHF-A):
PHONO (MM): 91dB or more
PHONO (MC): 75dB or more
LINE: 105dB or more
Volume adjustment: New LECUA1000
Amplification circuit: ODNF 4.0
Output configuration: Bipolar 3-parallel push-pull
Damping factor: 260
Max. amount of tone control:
BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz
Power supply: 230V~(50Hz) / 115V~(60Hz)
Power consumption: 350W; 86W (under no signal), 0.4W (at standby)
External dimensions: 440(W) x 178(H) x 454(D) mm
Net weight: 25.0kg (main unit)
Accessories:
Remote control (RA-17A)
Power cable
