Frequency Response
|
41–22,000 Hz ±3dB
|
|
Recommended Amplifier Power
|
20—400 watts per channel
|
|
Horizontal Dispersion
|
30°
|
|
Vertical Dispersion
|
40" (101.6cm) line source
|
|
Sensitivity
|
91 dB/2.83 volts/meter
|
|
Impedance
|
6 Ohms, 1.6 @ 20kHz Compatible with 4, 6, or 8 Ohm rated amplifiers.
|
|
Crossover Frequency
|
400Hz
|
|
High Frequency Transducer
|
XStat™ CLS™ electrostaic transducer » Panel Dimensions: 40" x 8.6" (102 x 22cm) » Radiating Area: 344 in² (2,244 cm² )
|
|
Low Frequency Transducer
|
Two 8” (20.3 cm) high excursion, high-rigidity paper cones with extended throw driver assembly, non-resonance asymmetrical chamber format, bass reflex.
|
|
Components
|
Custom-wound audio transformer, air core coils, large steel laminate inductors, polyester capacitors, and low DF electrolytic capacitors
|
|
Inputs
|
Custom 5-way bi-wire tool-less binding posts
|
|
Weight
|
52 lbs. (23.6 kg)
|
|
Dimensions
|
59.2" x 9.4" x 20.7 " (150.3cm x 23.8cm x 52.6cm)
|
