Frequency Response
|
42–22,000 Hz ±3dB
|
|
Recommended Amplifier Power
|
20—300 watts per channel
|
|
Horizontal Dispersion
|
30°
|
|
Vertical Dispersion
|
34" (71cm) line source
|
|
Sensitivity
|
91 dB/2.83 volts/meter
|
|
Impedance
|
6 Ohms, 1.6 @ 20kHz Compatible with 4, 6, or 8 Ohm rated amplifiers.
|
|
Crossover Frequency
|
500Hz
|
|
High Frequency Transducer
|
XStat™ CLS™ electrostaic transducer » Panel Dimensions: 34" x 8.6" (86 x 22cm) » Radiating Area: 292 in² (1,892 cm² )
|
|
Low Frequency Transducer
|
8" (20.3cm) high excursion, high-rigidity paper cone with extended throw drive assembly, non-resonance asymmetrical chamber format; bass reflex
|
|
Components
|
Custom-wound audio transformer, air core coils, large steel laminate inductors, polyester capacitors, and low DF electrolytic capacitors
|
|
Inputs
|
Push style with banana jacks
|
|
Weight
|
35.5 lbs. (16.1 kg)
|
|
Dimensions
|
52.1" x 9" x 16.3 " (132.3cm x 22.9cm x 41.4cm)
|
