Frequency Response
|
56–23,000 Hz ±3dB
|
|
Recommended Amplifier Power
|
20—450 watts per channel
|
|
Horizontal Dispersion
|
30°
|
|
Vertical Dispersion
|
57" (145cm) line source
|
|
Sensitivity
|
90 dB/2.83 volts/meter
|
|
Impedance
|
6 Ohms, 0.7 at 20kHz Compatible with 4, 6, or 8 Ohm rated amplifiers.
|
|
Crossover Frequency
|
360Hz
|
|
High Frequency Transducer
|
XStat™ CLS™ electrostatic transducer. » Panel Dimensions : 57" x 8.6" (145 x 22cm) » Radiating Area : 490 in² (3,190 cm² )
|
|
Low Frequency Transducer
|
DualForce™ double diaphragm, triple stator dipole low-frequency electrostatic transducer » Panel Dimensions : 57" x 11.5" (144.8 x 29.2cm) » Radiating Area : 656 in² (4,228 cm²)
|
|
Components
|
Thick film on alumina substrate resistors, air core coils, polypropylene capacitors, and custom wound toroidal audio transformers
|
|
Inputs
|
Custom binding posts
|
|
Lighting
|
Light intensity dimmer controls
|
|
Weight
|
110 lbs. (50 kg)
|
|
Dimensions
|
70.32" x 25.75" x 14.69 " (178.6cm x 65.4cm x 37.3cm)
|
