| System Type |
Active Subwoofer, Bass Reflex Type |
| Frequency Range(-10dB) *1 |
31Hz-200Hz |
| Power Consumption1 |
300W |
| Dimensions (HxWxD) |
410mm x 400mm x 440mm (16.1" x 15.7" x 17.3") |
| Shipping Dimensions (HxWxD) |
485mm x 470mm x 505mm (19.1" x 18.5" x 19.9") |
| Net Weight |
19.6kg (43.2lbs) |
| Shipping Weight |
22.5kg (49.6lbs) |
| Input Connectors |
RCA x1, XLR x1 |
| Speaker Unit |
Woofer Unit : 308mm（12.1"）Cone, 65mm（2.6"）Voice Coil x 1 |
| Controls |
VOLUME
CROSSOVER (40Hz-80Hz-200Hz)
PHASE (0°- 180°) |
| Indicator |
Power (ON:Green LED, During Startup: Red LED) |
| Input Voltage |
AC 110V-120V 60Hz, 220V-240V 50Hz |
| Enclosure Construction |
15mm（0.6"）MDF |
